Choosing a Strip and Overlap

Use this simple matrix to choose the ideal strip width and overlap for your run-in shed curtains.

Personnel = Foot traffic
Light Duty = Foot traffic and pallet jacks
Heavy Duty = Motorized traffic with occasional foot traffic

Overlaps

Static Mount

• Header Mount
• Wall Mount
• Universal Mount
• Threaded Rod Mount (Just a Feature of Universal Mount)

Free-Standing Mount

• Supported from the floor up
• Used in open floors when you can support from above
• Click here for this style

Rolling Hardware

• Allow the strips to roll out of the way
• Ideal for complete access when strips are not needed
• Note the strips roll like a barn door and do not fold up
• Click here for this style

Tube Mount

• Fits up to 2" diameter pipe
• Each pipe clamp is 4” wide and holds 2 strips (overlapped)
• Click here for this style

Description

• Clear - Stays clear 20% longer
• Temperature Range - Between 0°F and +150°F.
• UV Absorber - Strips will not discolor
• Crystal Clear - Extrusion Clear Processing for maximum line of sight
• CFM and NFPA-701 flame retardant certifications
• 2 Year warranty on manufacturing defects - Strips
• Need other colors, click here?

Hole Spacing

If no hardware is needed and you want just the strips then select no hardware from the fill in form. You will get just the strips with holes punched every 2" (see example of 8" wide strip below). This allows the barn door curtains to fit the vast majority of curtain hardware on the market.

Ratings and Certifications

• CFM and NFPA-701 flame retardant certifications
• Exceeds OSHA requirements
• 5 Year warranty on manufacturing defects

Hole Spacing

The horse stall strip curtains come with holes punched every 2" (see example of 8" wide strip below). This allows the strips to fit the vast majority of curtain hardware on the market. Please note that you can also purchase the strips without any mounting holes. Some customers choose to use their own hardware and punch their own mounting holes onsite. Loop style is also available for mounting to bars and tubes. If you want your horse barn curtains to use just the strips then select "no hardware."

What is the spacing on the holes for the livestock strip curtains?

• The holes are on 2" centers as shown below. The below strip is an 8" wide strip but all of the strips have the same spacing so that the strips fit studded hardware systems.

Should I order the strips a little taller than the opening?

• Only if you are wanting the wall mount hardware. With wall mount hardware order the strips 6" taller and 6" wider than the opening you are trying to cover since you are mounting to the face of the opening. Otherwise order the strips to the exact size of the opening.

Are the height of the strips measured from the hole or the top of the strip?

• The height is measured from the top of the strip to the bottom of the strip. The holes are located .75" down from the top of the strip.

How do you cut the strips in the field?

• You use a utility knife and a straight edge to keep the cut straight.

Are the strips ready to hang and already punched?

• Yes, the barn strip doors are shipped out and ready to be hung right out of the box.

Lead Time

• Ships in 2-3 work days
• Ships UPS or FedEx. You can also specify your shipping account

Warranty

• Strips - 5 year warranty on manufacturing defects
• Hardware - Lifetime warranty on manufacturing defects
